Wood grapple for pallet forks
The wood grapple for pallet forks is a device used for transporting wood in the industry. Its powerful hydraulic cylinder ensures exceptional gripping strength, safely transferring heavy logs. The wood grabber is an economical solution, reducing the need for heavy equipment and increasing the efficiency of logistical operations.
Description
The wood grapple for pallet forks has a solid and durable construction, ensuring safe and long-lasting use. It is designed for easy mounting on various pallet trucks, making it a universal solution. The log grabber slides into place instead of the forks and is secured with two bolts. The equipment is easy to operate, minimizing the risk of errors during work. Additionally, its compact design facilitates storage and transport, making it ideal for spaces with limited room.
The wood grapple for pallet forksr features:
- Construction from S355 Grade Steel: The entire structure is made from S355 grade steel, ensuring exceptional strength and long product life.
- 12-Month Warranty: We demonstrate our confidence in the quality of our products by offering a 12-month warranty, providing our customers with additional peace of mind.
- Pallet Jack Frame Mounting: Quick attachment of the grabber to the ISO2/ISO3 forklift carriage.
A complete range of equipment for your enterprise! Don’t forget to check out other products in our range. We offer many forestry devices and accessories such as front wood grapple, wood grapple M, and wood grapple XL.
Discover our full range of forestry machines! Don’t wait, and explore the other innovative solutions we have prepared for you. With these, your enterprise will operate even more efficiently. We invite you to visit our website and explore the full range of products!
Main product features
The gripper is mounted on the pallet frame ISO A II standard, spacing 407mm.
Base made of a solid bar 80×40 mm.
Hydraulic cylinder with a diameter of 73 mm.
Hydraulic conduits: DN10 2SN double steel braid with 330 bar strength.
12-month warranty.
SID Wood grapple for pallet forks – specification
SID Wood grapple for pallet forks
Specification
| Type | Opening height | Weight |
| ISO2 |
1560 mm |
83 kg |
| ISO3 |
1740 mm |
95 kg |
The wood grapple for the ISO2 pallet frame is a forestry equipment that is shot blasted and powder coated. This is by far the most effective of the modern metal coating methods used today. Contrary to traditional (liquid) varnishes, powder paints guarantee smooth coatings, without cracks, stains, bubbles and wrinkles. They are used for protective, anti-corrosion and decorative painting of metal objects. The thermal resistance of the coating is approx. 100 ° C. The coatings are characterized by very good mechanical properties and high resistance to chemical agents. A special advantage of powder paints is their versatility (thanks to the possibility of obtaining coatings with various degrees of gloss in a wide range of textures and structures, in full RAL colors).
As part of our policy of continuous improvement, SID company may make changes to the technical specifications without prior notice. The information and graphics on our website are for informational purposes only. Certain equipment elements may be available as an option and are not part of the standard offer. To learn more about the warranty, safety standards, and products, please contact a SID company representative.
